What size is M10?
| Tap size | Basic major dia (mm) | Basic major dia (inch) |
|---|---|---|
| M8 x 1 | 8mm | .3150 |
| M10 x 1.5 | 10mm | .3937 |
| M10 x 1.25 | 10mm | .3937 |
| M12 x 1.75 | 12mm | .4724 |
Are M10 bolts 10mm?
M10 (10mm) Thread Size (T) 6.6mm Head Length (H) DIN 933 Manufacturing Standard.
What size hole is M10?
Metric clearance and tapping drill hole sizes.
| Size | Clearance Hole mm | Tapping Drill (std Pitch) |
|---|---|---|
| M10 | 11 | 8.5 mm |
| M12 | 14 | 10.25 mm |
| M16 | 18 | 14 mm |
| M20 | 22 | 17.5 mm |
What does M10 mean?
M10 means a 10 millimeter outer diameter for the bolt or whatever piece it is; M12 means 12 millimeters. The part after the ‘x’ is the pitch — how many mm a thread is wide. To figure out which you have, you can measure the existing part with calipers and a thread gauge.
How do I know if I have a M10 bolt?
If the size is M10 x 25, that would mean that the diameter is 10 mm….M10-1.0 x 20
- M = This designates the fastener is a metric size.
- 10 = The nominal diameter in millimeters.
- 1.0 = The thread pitch, or distance between threads, in millimeters.
- 20 = The fastener’s length, in millimeters.
What nut is on M10 bolt?
Metric Nut Sizes
| Nut Size (mm) | Diameter* (mm) | Height (mm) |
|---|---|---|
| Jam Nut | ||
| 8 | 13 | 4 |
| 10 | 17 | 5 |
| 12 | 19 | 6 |
What does M10 mean on a bolt?
M10-1.0 x 20 M = This designates the fastener is a metric size. 10 = The nominal diameter in millimeters. 1.0 = The thread pitch, or distance between threads, in millimeters. 20 = The fastener’s length, in millimeters.
What size hole do I drill for a M10 bolt?
What bolt size is used for your concrete fixings? We use a Fischer type M10 shield anchor. These are specified using a high-grade steel with a corrosion resistant zinc plated finish. The shield requires a 16mm hole to be drilled that is dust and debris free.
What does M10 and M12 mean?
Those are metric screw dimensions. M10 means a 10 millimeter outer diameter for the bolt or whatever piece it is; M12 means 12 millimeters.
What size is M10 bolt in inches?
Table 3.
| Metric | Closest Inch |
|---|---|
| M8-1.25 | 5/16-18 (Smaller) |
| M10-1.5 | 3/8-16 (Smaller) |
| M12-1.75 | 1/2-13 (Larger) |
| M14-2.0 | 9/16-12 (Larger) |
What are M10 bolts used for?
M10 bolts are a highly adaptable and strong fixing, which can be used in many applications within construction and at home. They are adjusted with either a spanner or wrench due to their hexagonal head and have a full or half threaded stem, so they can be used with a nut or in a tapered hole.
