What is the difference between unbraked and braked towing capacity?

Braked vs Unbraked Towing Capacity Towing capacity on your vehicle will usually be specified as braked towing capacity. This is the maximum your vehicle can tow if your trailer has its own brakes. Unbraked towing capacity is the maximum your vehicle can tow if your trailer has no brakes.

What is the maximum weight for an unbraked trailer?

750kg
Assuming you can drive a car legally, no special categories are required on your driving licence to tow an unbraked trailer. The trailer has to have a gross weight of no more than 750kg.

At what weight should a trailer be braked?

A Braked Trailer “A trailer with a Gross Vehicle Weight from 751kg up to 3,500kg is required to have brakes, normally over-run (inertia) brakes that operate automatically are fitted.”

How are towing weights calculated?

Towing capacities are calculated by a number of maximum weight limits. The three most important numbers for you are Gross Vehicle Mass (GVM), Gross Trailer Mass (GTM), and Gross Combined Mass (GCM). In short, the GCM must be less than the sum of the GVM and the GTM combined.

What is braked and unbraked towing?

Braked weight is the maximum weight of a trailer, caravan, boat trailer or horsebox that has its own brakes. Unbraked weight is the maximum weight of a trailer, caravan, boat trailer or horsebox that is not capable of braking independently. In most cases, you are allowed to tow more braked weight than unbraked weight.

What does unbraked mean?

What is the difference between unbraked and braked trailers? An unbraked trailer has no brakes fitted so the car towing it does all the braking. A braked trailer has brakes fitted that are often known as ‘overrun brakes’.

What’s unbraked towing?

What is the difference between unbraked and braked trailers? An unbraked trailer has no brakes fitted so the car towing it does all the braking. A braked trailer has brakes fitted that are often known as ‘overrun brakes’. The trailer will apply its brakes through a mechanical linkage that is connected to the tow bar.

What does unbraked capacity mean?

Un-braked towing capacity. Refers to the ATM of the trailer which does not have its own brakes. This is significantly less than the braked towing capacity as the vehicle has to absorb much of the braking force.

What is meant by braked towing capacity?

Braked Towing Capacity. Refers to the ATM of the trailer which has its own brakes. Un-braked towing capacity. Refers to the ATM of the trailer which does not have its own brakes.

What is meant by a braked trailer?

A braked trailer has brakes fitted that are often known as ‘overrun brakes’. The trailer will apply its brakes through a mechanical linkage that is connected to the tow bar. When the car brakes, it puts a force through the tow bar which then activates the linkage to apply the trailer’s brakes.

What do towing weights mean?

Towing capacity refers to how much weight you can safely pull behind your truck with a trailer. The GCVWR is the maximum weight of your loaded truck and the weight of its attached trailer. Towing Capacity = Gross Combined Vehicle Weight – Curb Weight. Let’s say your truck has a GCVWR of 15,000 lbs.

What is Ball weight for towing?

Tow Ball Load is the proportion of the trailer weight that is applied (vertically) to the rear of the tow vehicle. A vehicle’s Ball Load specification will be found in the vehicle’s handbook and will be listed as a weight in kilograms or as a percentage of the trailer’s ATM.
